كويز تفاعلي: اختبار الوحدة التاسعة

اختبار تجريبي شامل للوحدة التاسعة في مادة الرياضيات.
يركز الاختبار على مفاهيم التحويلات الهندسية الصلبة مثل الإزاحة والانعكاس والدوران، وعلاقتها بتطابق الأشكال.
كما يتناول موضوع تشابه المضلعات والمثلثات واستخدام التناسب لإيجاد الأطوال المجهولة في تطبيقات حياتية وقياسات غير مباشرة.

Question 1

DB question no.: 1

Points: 1

Two figures are considered congruent in the coordinate plane if:

Read the article explaining this question

Question 2

DB question no.: 2

Points: 1

Look at the two triangles ABC and DEF in the coordinate plane. Determine if they are congruent and identify the sequence of transformations that maps ABC onto DEF.

Read the article explaining this question

Question 3

DB question no.: 3

Points: 1

Parallelogram CAMP is congruent to parallelogram SITE. Which sequence of transformations maps parallelogram CAMP onto parallelogram SITE?

Read the article explaining this question

Question 4

DB question no.: 4

Points: 1

Manuel created a logo where Figure A is the preimage and Figure B is the image. What transformations could be used to create this logo, and are the two figures congruent?

Read the article explaining this question

Question 5

DB question no.: 5

Points: 1

In the quilt design shown, it is given that $RST \cong RWX$. If the measure of angle WXR is 62 degrees, what is the measure of its corresponding angle STR?

Read the article explaining this question

Question 6

DB question no.: 6

Points: 1

In the roof construction shown, triangle $ABC \cong DEF$. If AB = 8.5 feet and AC = 10 feet, what is the length of EF? (Round your answer to the nearest tenth).

Read the article explaining this question

Question 7

DB question no.: 7

Points: 1

If triangle ABC is similar to triangle DEF, which of the following must be true about their angles?

Read the article explaining this question

Question 8

DB question no.: 8

Points: 1

Which sequence of transformations can be used to show that two figures are similar but not necessarily congruent?

Read the article explaining this question

Question 9

DB question no.: 9

Points: 1

Which of the following conditions is REQUIRED for two polygons to be considered similar?

Read the article explaining this question

Question 10

DB question no.: 10

Points: 1

If $ABC \sim XYZ$, which angle in the second triangle corresponds to angle B?

Read the article explaining this question

Question 11

DB question no.: 11

Points: 1

Samantha made a design using two similar quadrilaterals. The smaller quadrilateral has side lengths of 6 cm, 8 cm, 8 cm, and 14 cm. She enlarged it to create a larger quadrilateral using a scale factor that increased the 6-cm side to 9 cm. What is the total length of craft wire Samantha used for both quadrilaterals?
